    New Hydraulic Rubber Hose Crimping Machine Big Pipe Crimping Machine

    Ask Lasest Price
    Brand Name : MENSION
    Model Number : MS-P150
    Certification : CE RoHS
    Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram
    Supply Ability : 1000 Sets Per Month
    Delivery Time : 2 - 7 Working Days
    Price : Contact Us
    • Product Details
    • Company Profile

    New Hydraulic Rubber Hose Crimping Machine Big Pipe Crimping Machine


    RUBBER HOSE CRIMPING MACHINE MS-P150


    DESCRIPTION


    MS-P150 is our newest rubber hose crimping machine. It has a super thin crimping head, enable a large bend fitting fed. By the way, this machine is equipped with a die set quick change device, the productivity improve much.


    ADVANTAGES


    1. Intelligent CNC control syste, stable performance;

    2. Fast speed;

    3. Multifucntional foot pedal;

    4. Super thin crimping head with advanced oil transfer channel.


    TECHNICAL DATA


    Model

    MS-P150 Rubber Hose Crimper

    Crimping Range

    14 - 87 (mm)

    Crimping Force

    380 (T)

    Hose Size

    1/4 - 2 1/2 (inch)

    Max. Opening

    61 (mm)

    Die Sets

    14

    Die Set Type

    P150

    System Pressure

    31.5 (Mpa)

    Accuracy

    0.01 (mm)

    Control

    UC

    Standard Voltage

    220 (V) / 380 (V)

    Motor Power

    3.75 (KW)

    Length

    720 (mm)

    Width

    970 (mm)

    Height

    1600 (mm)

    Weight

    1020 (KG)



    P150 CRIMPING MACHINE DIE SETS


    Die No.

    Crimping Range

    Length

    6*

    6 - 8 mm

    55

    8*

    8 - 10 mm

    55

    10*

    10 - 12 mm

    55

    12*

    12 - 14 mm

    55

    14

    14 - 16 mm

    55

    16

    16 - 19 mm

    55

    19

    19 - 22 mm

    55

    22

    22 - 26 mm

    70

    26

    26 - 30 mm

    70

    30

    30 - 34 mm

    70

    34

    34 - 39 mm

    75

    39

    39 - 45 mm

    75

    45

    45 - 51 mm

    90

    51

    51 - 57 mm

    90

    57

    57 - 63 mm

    100

    63

    63 - 69 mm

    110

    69

    69 - 74 mm

    110
    7474 - 80 mm110
    78*78 - 87 mm110

    NOTE


    - * for non standard die sets;

    - Customized die sets are available;

    - Special voltage 110V, 208V, 240V, 415V are availbale;
