    High Pressure Hose Crimper Machine Powerful Hydraulic Hose Pressing Machine


    POWERFUL HOSE CRIMPING MACHINE MS-P130


    DESCRIPTION


    MS-P130 high pressure hydraulic hose crimper machine is updated in the configuration and appearance for DX68 hose crimping machine. It has big crimping force, and die sets are with high hardness.


    ADVANTAGES


    1. Super thin head, for bend fitting;

    2. Advanced PLC control system, high performance stability;

    3. Foot pedal to free both the hand for holding big size hose.


    TECHNICAL DATA


    Model

    MS-P130 Hose Crimping Machine

    Crimping Range

    14 - 87 (mm)

    Crimping Force

    600 (T)

    Hose Size

    1/4 - 2 (inch)

    Max. Opening

    45 (mm)

    Die Sets

    10

    Die Set Type

    P130

    System Pressure

    31.5 (Mpa)

    Accuracy

    0.01 (mm)

    Control

    UC

    Standard Voltage

    220 (V) / 380 (V)

    Motor Power

    3.75 (KW)

    Length

    720 (mm)

    Width

    970 (mm)

    Height

    1600 (mm)

    Weight

    820 (KG)


    P130 HOSE CRIMPER DIE SETS


    Die No.

    Crimping Range

    Length

    6*

    6 - 8 mm

    55

    8*

    8 - 10 mm

    55

    10*

    10 - 12 mm

    55

    12*

    12 - 14 mm

    55

    14

    14 - 16 mm

    55

    16

    16 - 19 mm

    55

    19

    19 - 22 mm

    55

    22

    22 - 26 mm

    70

    26

    26 - 30 mm

    70

    30

    30 - 34 mm

    70

    34

    34 - 39 mm

    75

    39

    39 - 45 mm

    75

    45

    45 - 51 mm

    90

    51

    51 - 57 mm

    90

    57

    57 - 63 mm

    100

    63

    63 - 69 mm

    110

    69

    69 - 74 mm

    110
    7474 - 80 mm110
    78*78 - 87 mm110

    NOTE


    - * for non standard die sets;

    - Customized die sets are available;

    - Special voltage 110V, 208V, 240V, 415V are availbale;
