    Automatic DX68 Hydraulic Hose Crimping Machine Cable Wire Press Service

    Ask Lasest Price
    Brand Name : MENSION
    Model Number : MS-NC130
    Certification : CE RoHS
    Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram
    Supply Ability : 1000 Sets Per Month
    Delivery Time : 2 - 7 Working Days
    Price : Contact Us
    • Product Details
    • Company Profile

    Automatic DX68 Hydraulic Hose Crimping Machine Cable Wire Press Service


    FAMOUS BRAND HOSE CRIMPING MACHINE MS-NC130 DX SERIES


    DESCRIPTION


    MS-NC130 is a hose press crimping machine which is controlled by CNC technlogy. It has a big crimping force for hose up to 2.5 inch and compact structure with volume less than 0.5CBM. Suitable for sea shipping with low cost.


    ADVANTAGES


    1. Advanced PLC system, more stable and intelligent;

    2. Italian diameter control ruler;

    3. Japanese hydraulic valves;

    4. Unique cylinder designing, low maintenance cost.


    TECHNICAL DATA


    Model

    MS-NC130 Hose Crimping Machine

    Crimping Range

    14 - 87 (mm)

    Crimping Force

    650 (T)

    Hose Size

    1/4 - 2.5 (inch)

    Max. Opening

    31 (mm)

    Die Sets

    13

    Die Set Type

    P32

    System Pressure

    31.5 (Mpa)

    Accuracy

    0.01 (mm)

    Control

    MS

    Standard Voltage

    220 (V) / 380 (V)

    Motor Power

    3.75 (KW)

    Length

    650 (mm)

    Width

    550 (mm)

    Height

    650 (mm)

    Weight

    240 (KG)


    P32 HOSE CRIMPER DIE SETS


    Die No.

    Crimping Range

    Length

    6*

    6 - 8 mm

    55

    8*

    8 - 10 mm

    55

    10*

    10 - 12 mm

    55

    12*

    12 - 14 mm

    55

    14

    14 - 16 mm

    55

    16

    16 - 19 mm

    55

    19

    19 - 22 mm

    55

    22

    22 - 26 mm

    70

    26

    26 - 30 mm

    70

    30

    30 - 34 mm

    70

    34

    34 - 39 mm

    75

    39

    39 - 45 mm

    75

    45

    45 - 51 mm

    90

    51

    51 - 57 mm

    90

    57

    57 - 63 mm

    100

    63

    63 - 69 mm

    110

    69

    69 - 78 mm

    110

    NOTE


    - * for standard die sets;

    - Customized die sets are available;

    - Special voltage 110V, 208V, 240V, 415V are availbale;
